与门&与非门
GT74LVC1G10
This single 2-input positive-AND gate is designed for 1.65-V to 5.5-VVcc operation.
The GT74LVC1G08 performs the Boolean functionY=A-B or Y=A+B in positive logic.The CMOS devicehas high output drive while maintaining low static powerdissipation over a broadVcc operating range.
This device is fully specified for partial-power-downapplications using lof.The loff circuitry disables theoutputs,preventing damaging current backflow throughthe device when it is powered down.
特性
- Supports 5V VCC operation
- Inputs accept voltages to 5.5 V
- Provides down translation to VCC
- Low power consumption, 10-μA Max ICC
- ±24-mA output drive at 3.3 V
- Ioff supports live insertion, partial-power-down mode, and back drive protection
应用
- Active noise cancellation (ANC)
- Barcode scanner - Blood pressure monitor
- CPAP machine - Fingerprint biometrics
- HVAC: heating, ventilating, and air conditioning
- Network-attached storage (NAS)
- Server motherboard and PSU
- Software defined radio (SDR)
- Video communications system
