模拟开关
GT4717
The GT4717 is a dual-channel single-pole double-throw (SPDT) analog switch that is designed to operate from 2.5V to 5V.
The device can handle negative signal down to -3V. It features high-bandwidth(500 MHz) and low on-resistance (4Ω@4.5 V). This device is available packaged in UTQFN- 1.8×1.4-10L and MSOP-10.
特性
- Supply range: +2.5V to +5.0V
- -3.0V to V+ Signal Passing Ability
- On-Resistance: 4 Ω(TYP) @+4.5V
- Low on-state resistance: 3 Ω @5V
- High Bandwidth:400MHz
- Fast Switching Times: TON 15ns TOFF 11ns
- TTL/CMOS compatible
- Break-before-make switching
- Operation temperature range:-40°C to 85°C
- Micro size packages:UTQFN-1.8×1.4-10L, MSOP-10
应用
- Portable instrumentation
- Battery-Operated equipment
- Computer peripherals
- Cell phones
- PDAs
